Model: BC9307P Series
IP Code: IP66
Ex Code: Ex d e IIC T3/T4 Gb
Ex tb IIIC T195℃/T130℃ Db
Ambient temp.: – 50℃ to +55℃
Standard: GB3836.1, GB3836.2
IEC60079-1:2014, MOD
ATEX: EPT16 ATEX 2484 X
IECEX: IECEx EUT 17.0011X
We supply LED explosion proof lights up to 240W suitable for Several hazardous areas. It adopts Japanese Citizen LED COB chip, International Power driver, Special Aluminum alloy housing material. High quality and long-term lifetime.
Product Details
Application
Widely used in dangerous environments such as oil exploitation, refining, chemical, military, and offshore oil platforms and tanker lamps. Applicable to Zones 1 and 2 in Class IIA, IIB, IIC and explosive gas environments. T1-T6 group temperature group. Suitable for places with high protection and humidity.
Characteristics
- Alloy material: aluminum alloy shell of lamp body, high-voltage electrostatic spray on the surface, beautiful and durable.
- Anti-corrosion and durable: high corrosion resistance stainless steel exposed fasteners.
- Durable: tempered glass lens, resistant to 4J energy impact, heat fusion resistance, high light transmission. Flameproof + increased safety structure, more reliable explosion-proof performance.
- Patented design: Patented design heat dissipation structure to ensure long-term use of LED ex lamps.
- Reliable accessories: using international brand light source and power supply, reliable quality.
Technical Specification
Ordering Reference
|
Ordering reference |
Wattage |
Light output |
Space |
Mounting |
Equivalent to |
|
High Pressure Mercury Lamp |
|||||
|
BC9307P-L100 |
100W |
>11800lm |
1.25/1.75 |
8~12m |
250W |
|
BC9307P-L120 |
120W |
>13600lm |
>250W |
||
|
BC9307P-L150 |
150W |
>17300lm |
10~15m |
400W |
|
|
BC9307P-L180 |
180W |
>18900lm |
>400W |
||
|
BC9307P-L200 |
200W |
>23300lm |
>400W |
||
|
BC9307P-L240 |
240W |
>26700lm |
15~25m |
600W~800W |
