Model: BC9100 Series
IP Code: IP65
Ex Code: Ex de IIB T4/ T6 Gb
Ambient temp.: – 20℃ to +40℃
Standard: GB3836.1, GB3836.2
IEC60079-1:2007,MOD
Suitable for flammable gas and steam environment, such as Petrochemical Plant, Chemical Plant, Coal Washery, Pharmaceutical Factory, etc.
Product Details
Application
- Ideal to be used in the environment of flammable gas and steam environment, such as Petrochemical Plant, Chemical Plant, Coal Washery, Pharmaceutical Factory, etc.
- Zone 1, zone 2.
Characteristics
- Hazardous area lighting is equipped with international famous brand light source and electrical appliance, more stable performance and gives approximately 20% more light over the other manufacturer’ s.
- The average life span of the light source is more than 10000 hours. Therefore it is low maintenance.
- Two Explosion-proof cavities structure. The wiring cavity is separated from the main flameproof cavity, enhancing safety.
- Made of aluminum alloy, high strength. The spray coating treatment ensures the lamp waterproof, anti- corrosion.
Main Specification
| Item | Technical Parameters |
| Input voltage range | 220VAC |
| Input frequency | 50Hz |
| Light source | MH Mercury |
| Service life | 10000h |
| CCT | 3000K/4000K/5000K |
| Cable entry | G3/4″ |
| Leading-in cable diameter | φ9mm~φ10mm |
| Dimension | Lamp 400* 266* 207mm |
| Ballast 230* 220* 105mm | |
| Net weight | Lamp 5Kg |
| Ballast 3.8Kg |
Ordering Reference
|
Ordering |
Wattage |
Light output |
Space |
Mounting |
Temperature |
|
BC9100-J70 |
70W |
4725lm |
2.6 |
2~4m |
T6 |
|
BC9100-J70 |
100W |
6750lm |
3~5m |
T4 |
|
|
BC9100-J70 |
150W |
10500lm |
4~6m |
T4 |
