Model: BC9307P Series
IP Code: IP66
Ex Code: Ex d e IIC T3/T4 Gb
Ex tb IIIC T195℃/T130℃ Db
Ambient temp.: – 50℃ to +55℃
Standard: GB3836.1, GB3836.2
IEC60079-1:2014, MOD
ATEX: EPT16 ATEX 2484 X
IECEX: IECEx EUT 17.0011X
The lighting solution, professional advice, technical support and local distributors service will be provided depends on your requirement. Every explosion proof lights are tested for their performance, IP level, lighting effect by final quality control teams before delivery.
Product Details
Application
- Ideal to be used in the oilfield, chemical industry, offshore drilling platform, steel industry, petroleum, etc.
- Gas explosive environment: Group IIA, IIB, IIC.
- Zone 1, zone 2; zone 21, zone 22.
Main Specification
| Item | Technical specification |
| Rated voltage | 100~240VAC |
| Input frequency | 50Hz/ 60Hz |
| Light source | LED |
| Service life | 50,000h |
| CRI | Ra 70(80 Optional) |
| CCT | 3000K/4000K/5000K |
| Screw Thread | G3/4″, NPT3/4″, M25* 1.5 |
| Leading-in cable diameter | φ10mm~φ14mm |
| Terminals | Multi-core wire：≤2.5 mm2 |
| Single-core wire：≤4mm2 | |
| Dimension | φ300* 290mm |
| Net weight | 6.4 Kg |
Ordering Reference
|
Ordering Reference |
Wattage |
Light output |
Space height ratio |
Mounting height |
Equivalent to |
|
High Pressure Mercury Lamp |
|||||
|
BC9307P-L100 |
100W |
>11800lm |
1.25 |
8~12m |
250W |
|
BC9307P-L120 |
120W |
>13600lm |
>250W |
||
|
BC9307P-L150 |
150W |
>17300lm |
10~15m |
400W |
|
|
BC9307P-L180 |
180W |
>18900lm |
>400W |
||
|
BC9307P-L200 |
200W |
>23300lm |
>400W |
||
|
BC9307P-L240 |
240W |
>26700lm |
15~25m |
600W~800W |
