Explosion Proof Emergency Box With ATEX Certified Used as battery backup for light at low installation height equipment area, like petrochemical plants, chemical plants, pharmaceutical factory, polishing plant, etc.
Model: BXP01 Series
IP Code: IP66
Ex Code: Ex d IIC T6 Gb
Ex tD A21 T80℃
Ambient temp.: – 50℃ to +60℃
Standard: GB3836.1, GB3836.2
IEC60079-1:2007,MOD
ATEX Cert NO.: INERIS 16ATEX0008X
IECEX Cert NO.: IECEx INE 16.0017X
Product Details
Application
- This flameproof emergency box is suitable for low installation height equipment area, like petrochemical plants, chemical plants, pharmaceutical factory, polishing plant, etc.
Characteristics
- Explosion proof emergency box has the characteristics of small volume, light weight, convenient installation, etc.
- The shell of ATEX lighting accessories adopts anti-corrosive processing, standard for the 304 stainless steel material, using high-tech surface anti-corrosion treatment technology, applicable to all kinds of bad industrial environment.
Technical Specification
| Item | Technical specification |
| Input voltage range | 100~ 240VAC |
| Input frequency | 50Hz/ 60Hz |
| Service life | 6000h |
| Rated Capacity | 2.6Ah/ 14.8V |
| Cable entry | G3/4”, M25* 1.5, M20*1.5, NPT3/4”, NPT1/2 |
| Diameter | 238* 222* 106mm |
| Net weight | 2.9 Kg |
Ordering Reference
|
Ordering |
Wattage |
Emergency Duration |
|
BXP01 |
10W |
180min |
|
20W |
90min |
|
|
30W |
60min |
