Application

• Idea to be used in the platform water control room, fire water pump room and etc.

Characteristics

Optical system characteristics

1. Preferably into the chip, with a special lumen maintenance and light efficiency.
2. Using surface mount technology to greatly improve thermal conductivity.
3. Using COB international brand light source, can achieve rapid disassembly and maintenance.

Drive system features

1. It adopts constant current drive and has short circuit and over voltage protection functions.
2. LED flood lamp can do integrated emergency function, easy to install, simple. The emergency power reduction function can be activated to save energy and improve the fire safety function in an unmanned environment.
3. Excellent compatibility, will not cause interference to other electrical appliances, can make the voltage tolerance fluctuation of 25%.
4. The drive adopts the glue sealing process to ensure the components are cooled and not corroded.

Whole lamp structure characteristics

1. The standard heat dissipation structure, the power supply cavity, the light source cavity and the wiring cavity are independently cooled, and they do not affect each other.
2. Exposed fasteners and accessories are made of 304 stainless steel, which has stronger anti-corrosion performance.
3. The use of integrated emergency, no additional distribution box, easy to install and repair.
4. The installation method can be selected by pole type, street lamp type, etc., all kinds of accessories are complete.

Technical Specification

 Ordering Reference

Product Details
